Monoshaft Multiblade circular saw Piranha 310: a little big discovery!
the Monoshaft Multiblade circular saw Piranha 310 is the smallest of the category. With a maximum working width of 300mm and a height of 100mm, it can reach a maximum working height of 120mm, with the optional kit available. Small, yes, but an excellent ally in a modern sawmill to optimize the production of sawn timber, strips, squares, profiles, edged boards, prisms, tablets, elements for pallets.
| Description | Details | |
| Toothed-belt width | mm 320 | |
| Max saw group width | mm 300 | |
| Max cut height mm | mm 100 | |
| Max cut height | (optional kit 312) | mm 120 |
| Min. Workpiece length | mm 600 | |
| Max width mm | mm 650 | |
| Saw spindle diameter | mm 60 | |
| Blades max diameter | (360 mm with kit 312) | mm 350 |
| Saw hole diameter | mm 80 | |
| Working speed | mt/min 4-26 | |
| Weight | 2.300 – 2.500 Kg | |
| Overall dimensions | mm 1670x1750x1500 |
Compatible and combinable with our products (such as the pneumatic roller conveyor), the Monoshaft Multiblade circular saw Piranha 310 is ready for your challenges!
Some reasons to choose our Multiblades:
- from the smallest to the largest, all our machines are designed with advanced, innovative and technological construction systems;
- special carpet in ductile iron with a new design and easy to maintain;
- Floor interrupted in the cutting area, to avoid cutting it, since it remains one of the most expensive parts of the machine;
- feed with special rollers to work at high speeds;
- no “witness” with the cut on the Bi-tree;
- total operator safety as there are no metal-metal collision points between the introducer and the belt, and has 2 splinter guard barriers and 2 backstop barriers according to the latest directives;
- Top of the class for silence: it has a system where the motor is anchored that absorbs the inertia of the same; A perfect workmanship guarantees a non-welded structure, but pinned and bolted, anti-deformation: practically a do-it-yourself, with total elasticity, absorbing all work stresses and vibrations;
- All mechanical parts are easily accessible for simple and convenient maintenance;
- Rich control panel for easy and safe work;
And also:
- Ammeters in sight for motor absorption control;
- Inverter to prevent the wood-blade ratio from being exaggerated, without causing any damage, safeguarding the transmission components;
- Special steel shaft, centesimal ground, with balancing of the same at 4,000 revolutions;
- Large diameter blade holder shaft to avoid stresses of the same;
- Hard aluminum spacer rings to avoid rust formation in the case of wet wood processing, in addition to the supply of very low thickness steel rings for sharpening correction;
- Special high precision ring nut, unscrewing, and special key for easy opening;
- Independent presser with structure anchored on two chromed stems for easy and precise handling by means of trapezoidal screws and thick nuts, protected by dust caps and wood splinters;
- Perfect parallelism of the pressure group on the work surface;
- It is considered the first in its class ever, with a 20/30 mm steel structure, where all the mechanical parts are anchored;
- Unbeatable quality / price ratio;
- Cutting-edge technology with over 35 years of direct experience in biting We are Trademak, whoever works with our machines will never buy anything from the competition. 100% RELIABILITY and WARRANTY
Have you seen our 2-Shafts Multiblades?
Visit us on Machineseeker too!
Video: https://www.youtube.com/watch?v=kqS3maXcPBA&feature=youtu.be
